Basic Info.

Model NO.	TP-5000E
Loading Method	See The Operation Manual
Display	Digital
Control	Computer Control
Weight	0-100Kg
Power Source	AC220V
Oil Cylinder Position	See The Operation Manual
Transport Package	Packed in Wooden Case and Box
Trademark	TOP
Origin	Chongqing
Production Capacity	100

Product Description

Application
The repeatability and reproducibility for calorific value testing of this instrument is better than requirements in standards GB/T 384 Determination of Calorific Value Of Petroleum Products and GB/T213-2008 Determination Method Of Calorific Value Of Coal. It is mainly composed of constant temperature calorimeter system and single chip microcomputer control system etc, and is a supermatic calorimeter which is automatically controlled by single chip microcomputer system and can carry out data processing. This instrument is mainly applied for calorific value testing of combustible materials such as coal, petroleum, chemicals, food, wood, explosives etc. When testing out the calorific value of bomb, at the same time it gives out the corresponding high and net calorific powers.
Features

1. Advanced SCM with simple structure, reliable performance and high disturbance resistance.
2. No need of weighing water and adjusting the water temperature to reduce work intensity and improve measuring precision. It can automatically add water, discharge water, stir, ignite, acquire temperature, calculate, calibrate, print. The testing process achieved fully automation to avoid operative error.
3. It automatically cools down and calibrate. Testing environment requirement is low. It improves testing environment accuracy at the same time ensures the long time stability of instrument.
4. With high and low, J and K automatic conversion function. Operation is simple.

6.











7. Technical Specifications

   No.	Item		Specification	Unit
   1	Heat capacity		Around 10500	J/K
   2	Oxygen bomb	Volume	300	ml
   		Oxygen filling pressure	2.8-3.0	Mpa
   		Pressure withstand performance	Water pressure 20	Mpa
   		Weight	2.5	Kg
   		Size	Ø86.2×181	mm
   3	Outer water cylinder capacity		51	L
   4	Inner cylinder water capacity		Around 2.1	L
   5	Display range		0.000-40.000	ºC
   	Response time		<4	s
   	Resolution			ºC
   	Linearity		0.0001
   	Temperature testing error		Within each 5ºC rising range precision ±0.003ºC
   6	Operation power supply		AC:220V±10%	V
   7	Humidity		≤80%
   8	Power		30		W
   9	Ignition voltage		AC:24		V
   10	Ignition time		5		s
   11	Total weight		Around 21.5		Kg
